Contact form |
1D (SPST-NO) |
|
Contact material |
Silver alloy |
|
Contact load (resistive load) |
100A |
| Contacts |
Normally open contacts |
|
Insulation resistance |
Min. 10MΩ at 500VDC |
|
Dielectric Strength |
1000VAC 50 HZ/60 HZ (1 minute) Leakage current less than 1mA |
|
Instantaneous maximum current |
300A ,≤1S |
|
Pull in time |
Max. 30mSec. |
|
Release time |
Max. 50mSec. |
|
Pull-in voltage (DC V) |
≤75% US |
|
Release voltage (DC V) |
5～40% US |
|
Operating ambient temperature |
-25℃~+55℃ |
|
Degree of protection |
IP67 |
| Working system |
Short term working system |
|
Vibration |
（10～200）Hz acceleration ≤3.5g |
| to attack | （60） Times / minute acceleration 6g |
|
Mechanical life |
≥300000 Times |
